VersiControl™ Addressable RGB(W) Smart System Plus
SKU: 2300A
This true RGB(W) controller provides fades, chasing modes, and a virtually unlimited color palette. Able to independently control two RGB(W) and two addressable zones, this intuitive system makes lighting control functional and fun.
-
VersiControl™ Guide
-
N2K Certified
-
3-Year Warranty
-
Download App
Housing Material Specs
Controller - Steel Reinforced Plastic
Pad Controller - Plastic
Voltage Specs
11-28V DC
Current Specs
Controller - 20A Max / 12A per zone
Pad Controller - 0.5A Max
Remote Distance Specs
Controller - 100 FT
Pad Controller - N/A
Bluetooth Version
Controller - Bluetooth 4.0 BLE (Operating system: IOS 10.0/Android 5.0 or greater)
Pad Controller - N/A
IP Rating
IP66
UV Stable
Yes
Operating Temperature
-4°F - 120°F
VersiControl Addressable RGB(W) Smart System Plus Technical Specs
VersiControl Smart System Plus Install Instructions
VersiControl Smart System Plus J1939 Wiring Diagrams
VersiControl Smart System Plus NMEA Wiring Diagrams
VersiControl Smart System Plus RV-C Wiring Diagrams
VersiControl Smart System Plus Software Update Instructions
VersiControl® Quickstart Guide
